| Weight |
M - 23.67 kg / 52.18 lbs (with tubes) |
| Frameset |
| Frame |
Alpha Platinum Aluminum, Removable Integrated Battery (RIB), tapered head tube, Control Freak internal routing, Motor Armor, Boost148, 12mm thru axle |
| Fork |
SR Suntour XCM 34, coil spring, preload, lockout, tapered steerer, 44mm offset, Boost110, 15mm thru axle, 80mm travel |
| Wheels |
| Front Hub |
Formula DC-511, 6-bolt, Boost110, 15mm thru axle |
| Rear Hub |
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano 8/9/10 freehub, Boost148, 12mm thru axle |
| Rims |
Bontrager Connection, double-wall, 32-hole, 20mm width, presta valve |
| Tires |
Bontrager XR3 Comp, wire bead, 30tpi, 29x2.30" |
| Drivetrain |
| Shifters |
Shimano Deore M4100, 10 speed |
| Rear derailleur |
Shimano Deore M5120, long cage |
| Crank |
FSA Bosch CK-220, 36T ring, 165mm length |
| Cassette |
Shimano Deore M4100, 11-46, 10 speed |
| Chain |
KMC X10, 10 speed |
| Pedals |
VP-536 nylon platform |
| Components |
| Saddle |
Bontrager Commuter Comp, 165mm width |
| Seatpost |
Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
| Handlebar |
Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
| Stem |
Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length |
| Grips |
Bontrager XR Endurance Comp, lock-on |
| Headset |
FSA IS-2, 1-1/8" top, 1.5" bottom |
| Brakeset |
Tektro HD-M275 hydraulic disc, 203mm rotors |
| Accessories |
| Battery |
Bosch PowerTube 500 |
| Controller |
Bosch Purion |
| Motor |
Bosch Performance CX, magnesium motor body, 250 watt, 75 Nm, 25km/h |
